Crankshaft Grinding Machine

MSRADIX® MS Series Rotary Gear Pumps are self-priming, compact, low noise, efficient, easy maintainable, cost economical for handling viscous and semi-viscous liquids.

Specification

Features :

This Crankshaft Grinding Machine is a Unique, Easy Operation, Rigid Strength, and Beautiful Design
High Productivity, Less Effort of Workmanship
It comes with Air Float Head Stock & Tail Stock, Centrally Lubrication System for Table Slide & Wheel Head Slide, Unique Work Head Belt Tensioner for Balancing Crankshaft
Fast Hydraulic Movement for Wheel Head, VFD Control Work Head RPM, Head Stock & Tail Stock Fitted with Tapper Roller Bearing for Continuous Accuracy & Long Lasting Life

STANDARD ACCESSORIES	QTY	EXTRA ACCESSORIES (OPTIONAL)
Centering Stand	1	Grind Wheel Balancing Stand
Normal Steady Rest	1	Continuous Sizing Gauge
“V” Guide	1	Pair of Weight
Radius Dresser	1
Flat Dresser	1
Coolant Tank	1
Flush Guard	1 Set

TECHNICAL SPECIFICATIONS

MODEL	M-600	M-1000	M-1200	M-1500	M-1800	M-2000
SIZE	24”	40”	48”	60”	71”	84”
Max. Distance Between Centre (mm)	600	1000	1200	1500	1800	2000
Max. Distance Between Chucks (mm)	600	900	1100	1400	1800	2000
Max. Offset Centre (mm)	65	75	80	85	110	125
Fast Hyd. Wheel Head Traverse (mm)	80	100	100	125	150	150
Max. Grinding Wheel Diameter	500	600	660	710	760	810
3 Jaw Chuck (2 Nos.) (mm)	200	200	200	200	200	200
Max. Grinding Diameter (mm)	100	125	125	150		175
Power 380V, 3 Phase, 50 Cycles
Wheel Head Motor (HP)	2.00	3.0	4.00	5.00	7.50	7.50
Work Head Spindle Motor (HP)	0.25	0.50	0.50	1.00	1.00	1.50
Hydraulic Power Motor (HP)	0.25	0.50	0.50	0.50	0.50	0.50
Coolant Pump (HP)	0.08	0.08	0.08	0.08	0.08	0.08
Machine Dimension (mm)
Nett Weight (Kgs.)	1500	2100	2500	3000	3550	6000
Shipping Dimension (Inches)				118x60x70	130x62x70
Gross Weight in Kgs. (approx.)
